oPod™ Mini
Autonomous Buoy for Real-time Marine monitoring
Scalable to fleet deployment
Each unit is designed for oPod network compatibility, ready for interlinked, fleet-scale deployments.
The oPod™ Mini is a compact, self-powered, multiparameter marine monitoring buoy for ocean and coastal deployments.
At 49kg, it can be deployed by two operators from a small vessel for rapid, low-cost installation allowing users to deploy and collect data with no technical expertise required (recommended handling guidelines apply).
Durable multi-parameter sonde
Measured parameters include temperature, pH, dissolved oxygen, salinity, turbidity, and chlorophyll-a. The sonde is equipped with a self-cleaning brush that effectively cleans the measurement surface, removes bubbles, prevents microbial attachment, and ensures stable performance.
Package Includes
-
oPod™ Mini buoy hull
-
Multiparameter sonde
-
Telemetry and data logging module
-
Solar panel + battery
-
Integrated mounting hardware
-
50 m waterproof cable (optional)
Physical Specifications
Typical footprint:
~4.5 m x 4.5 m
Typical total height:
~25 m (including~20m submerged intake)
Configurable for site conditions
Intake depth and system geometry adapted to water depth, bathymetry, and distance from shore
Designed for integration
Compatible with pipeline delivery to shore or connection into existing water infrastructure
Production: ~20-25 m³/
day per unit
Deployment: ~12 weeks
(manufacture toinstallation)
Energy: Fully offshore. no
grid connection required
Scaling: Linear and predictable
through modular deployment
Measured Parameters
Parameter | Range | Resolution | Accuracy | Principle |
|---|---|---|---|---|
Chlorophyll-a | 0-500 µg/L | 0.01 µg/L | ±5% or 0.5 µg/L, take the
bigger one | Fluorescence |
Temperature | 0.5-55°C | 0.1°C | ±0.3°C | PT1000 |
Turbidity | 0-1000 NTU or 0-4000 NTU | 0.01 NTU | ±5% or 0.3 NTU, take the
bigger one | Scattered light |
Dissolved Oxygen | 0-50mg/L or 0-500% saturation | 0.01 mg/L | 0-20mg/L: 1% or ±0.2mg/L;
>20mg/L: ±5% or ±0.6mg/L | UV fluorescence |
Conductive Salinity | Conductivity: 0-200mS/cm
(0-2mS/cm, 2-20mS/cm, 20-
200mS/cm); Salinity: 0-175ppt;
TDS: 0-128000mg/L | 1uS/cm | ±1% or 0.01mS/cm, take the
bigger one; ±1ppt | Electrode method |
pH | 0-14 pH | 0.01 | ±0.02 pH | Glass ion selective |
Physical Specifications
Operational Advantage
-
Low recovery operation (~9°/0)
Reduces fouling, extends membrane life, and lowers maintenance requirements -
Near-ambient brine discharge
Simplifies environmental approvals and reduces discharge impact -
Improved feedwater quality
Offshore intake accesses cleaner, more stable water, reducing pretreatment and chemical use -
Reduced operational risk
lower exposure to algal blooms, oil spills, and coastal contamination events improves system reliability
Modular Scaling
-
Plug-and-play RO modules
Enable rapid maintenance, simplified servicing,
and minimal downtime -
Standardised units deployed in parallel:
- 5 units: ~100-125 m3/day -
Linear, predictable scaling
Allows capacity to be increased incrementally to meet demand -
Staged deployment
Reduces upfront capital investment and enables capacity
to align with operational needs
Platform Value
Blue Carbon provides the intelligent offshore monitoring platform that enables oPod™ Mini to operate as AI-supported "eyes in the water":
-
Continuous real-time monitoring of offshore conditions and asset performance
-
Compact intelligent buoy technology for rapid deployment in remote environments
-
AI-supported insights and alerts, reducing the need for constant manual oversight
-
Enables operators to focus on higher-value tasks while oPod™ Mini observes, reports, and learns in the background
Find out more: oPod™ System
For more information about the oPod™ System please share your details, and a team member will contact you.
